Larger block sizes with XFS on a Proxmox VM

In a previous article in this series we discussed the convenience of aligning block sizes across different layers of the storage stack, especially when using ZFS volumes (ZVOL).

When our average workload is located beyond the typical 4K block size, using XFS becomes advantageous due to its support for larger block sizes and efficient handling of large files.

However, the kernel’s page size, which defaults to 4K on Debian, will still be a limiting factor, unless we decide to compile our own kernel from sources. Fortunately, there is a way to work around this limitation via the Large Block Sizes (LBS) feature in the kernel.

This feature is still marked as experimental in the 6.12 LTS kernel that Debian 13 Trixie ships with, but we can experiment with it while we wait for a more modern kernel version to be backported into it (LBS was marked stable in kernel 6.13). Moreover, Debian 13 ships with a modern-enough version of xfsprogs that supports LBS.

Large Block Size

#

Support for Large Block Size (LBS) in the Linux kernel was marked as stable in version 6.13. This support focused on enabling larger block sizes for I/O operations, moving beyond the traditional 4 KB page size default.

The goal is to improve performance and efficiency via:

• Reduced overhead, as the number of individual I/O operations is reduced.
• Hardware efficiency, as modern storage devices (e.g., NVMe drives) come with a default sector size of 8 KB.
• Application needs, as some applications (e.g., databases) may have specific internal data structures that align better with larger block sizes.

This involves changes to the block layer, filesystems, and potentially memory management with folios.

PostgreSQL, for example, uses an 8 KB page size internally. With LBS, we can now create an XFS filesystem with an 8 KB block size, matching the database’s internal page size, which can improve performance and reduce overhead when writing data.

To use it, all we have to do is format the XFS filesystem with the desired block size using the mkfs.xfs command with the appropriate option.

About XFS

#

XFS is a 64-bit high-performance journaling filesystem optimised for very large files¹ and filesystems², and high-throughput workloads. It is completely multi-threaded and supports extended attributes and variable block sizes, making it a strong choice inside virtual machines.

Designed from day one for computer systems with large disk arrays and many CPUs, its robustness under concurrent write-heavy operations and support for advanced features, like delayed allocations and online defragmentation and resizing, make it particularly well-suited for use cases such as NFS shares, backup storage, and databases.

XFS itself did not originate on Linux, but was first released in 1994 on IRIX, a UNIX variant for SGI workstations and servers. Starting in 1999, XFS was ported to Linux as part of SGI’s push to use Linux.

As a journaling file system, XFS keeps record of modifications before they are committed to its internal structures, which ensures its overall consistency in case of a crash or power loss.

Debian kernel

#

Debian 13 Trixie comes with kernel 6.12 LTS and modern userland tools (the xfsprogs package) that support Large Block Sizes (LBS) in XFS. Unfortunately, LBS is marked as experimental in kernel 6.12 LTS.

In essence, kernel 6.12 introduced the fundamental Virtual File System (VFS) infrastructure and initial XFS support for Large Block Sizes, making the concept viable. Then kernel 6.13 added critical features like atomic write support for major filesystems (EXT4, XFS), improving general large file handling, and incorporating the usual wave of bug fixes and optimizations that are essential for a feature to be considered truly stable and production-ready.

Maintenance of version 6.12 by the Linux Kernel Organization is restricted to patches that fix security issues, bugs or regressions, or provide stability. However, while we wait for a more modern kernel (hopefully 6.15+) to be backported to Trixie, we can check it out and test it.

Regarding userspace tools, Debian 13 ships with xfsprogs version 6.13, which means we will have:

• Full userspace support for LBS filesystems.
• All the maintenance tools that understand larger block sizes.
• Proper compatibility between kernel and userspace tools.

Aligning block sizes

#

We want to match the same block size that Proxmox used to create the ZVOL (volblocksize) to the block size of XFS. Because volblocksize can change depending on the version of zfsutils-linux, start by checking out its value via the terminal of the host before formatting the disk of your virtual machine.

List the existing ZVOLs using zfs list, then use zfs get volblocksize to check the block size of the specific ZVOL.

# zfs get volblocksize zfspool/vm-104-disk-0
NAME                   PROPERTY      VALUE     SOURCE
zfspool/vm-104-disk-0  volblocksize  8K        default

When formatting the disk, convert the value of volblocksize into bytes. For the example above, inside the VM you would use 8192 bytes.

mkfs.xfs -b size=8192 /dev/sdc

The mkfs.xfs command returns the geometry information for the file system to make sure all parameters are set correctly.

ZFS version 2.2 brings in a new default block size of 16K.

The mkfs.xfs command will fail if the block size is not supported by the kernel.

Using XFS

#

The xfsprogs package provides a set of utilities for managing XFS filesystems, including tools for creating (mkfs.xfs), checking and repairing (xfs_repair), and extending (xfs_growfs) a filesystem.

Formatting

#

Let’s say that our VM has a data disk we are using to store the files served by our NFS server, or the databases in our PostgreSQL server. When formatting the disk, we want to align the block sizes of our XFS filesystem with the underlying ZFS storage.

Recent versions of xfsprogs allow us to specify both the block size and the sector size when using mkfs.xfs. Aligning both will get us better performance.

As of Debian 13 with kernel version 6.12, the following command can be used to format the disk with an 8K block size and a 4K sector size:

mkfs.xfs -b size=8192 -s size=4096 /dev/sdc

When a kernel 6.15+ is available, we will be able to specify larger sector sizes. Should our volblocksize be 16k, the following command would make the I/O requests even more performant:

mkfs.xfs -b size=16384 -s size=16384 /dev/sdc

Sector size

#

By default, mkfs.xfs uses a 512-byte sector size, which matches what the ZVOL exposes. The ZVOL defaults to such sector size mainly due to two reasons:

• Legacy compatibility. Many OS, boot loaders, and even BIOS/UEFI implementations historically expect 512-byte logical sectors, and may even refuse to mount or format a disk if it reports something unusual.
• Alignment problems. By advertising 512-byte logical sectors, ZFS makes it harder for the guest filesystem to get misaligned (from ZFS’s point of view), as every alignment is a multiple of 512.

Although ZFS abstracts the physical layer, volblocksize is its true internal allocation unit. However, it does not tell the guest about it so that it can present a safe virtual disk that works on any OS regardless of its sector size support.

However, if the guest filesystem knows that the real storage prefers, for example, 16 KB writes, it can:

• Batch I/O so it writes in 16 KB multiples.
• Work around the RMW penalty.

Then, ZFS can directly map filesystem blocks to ZVOL blocks without fragmentation or partial-block writes.

Batching I/O requests is about how the filesystem plans writes in the first place. If XFS believes the sector size is 16 KB, it will naturally coalesce smaller logical changes into 16 KB-aligned writes before sending them to the block device.

Avoiding RMW cycles is about what happens if a write is smaller than the underlying ZFS volblocksize when it finally hits ZFS. If ZFS gets a sub-16 KB write:

1. It reads the whole 16 KB block from disk.
2. It modifies just the changed part (e.g., the 512-byte region).
3. It writes the whole 16 KB block back.

That is the read-modify-write penalty, which happens down in the storage layer.

Therefore, when we set, for example, -s size=16K in XFS, we get both:

1. Fewer small writes generated, thanks to batching/alignment.
2. No RMW cycles triggered in ZFS, because it only ever sees full 16 KB writes.

ZFS defaults to lying for maximum compatibility, leaving it to the VM admin to override if the guest OS can handle larger sectors.

Mounting

#

Once the disk has been formatted, we need to mount it:

mount -t xfs -o noatime,logbufs=8 /dev/sdc /srv/nfs

Given the nature of our workload, both of these options are good, low-risk optimisations:

• noatime tells XFS not to update the access time metadata every time a file is read. This skips extra writes for read operations, reduces metadata churn and slightly improves performance and reduces wear on SSD devices.
• logbufs=8 tells XFS to use 8 in-memory log buffers for the journal (i.e., the write-ahead log). This increases parallelism for metadata logging, allows more outstanding metadata transactions before forcing a flush and can improve performance in metadata-heavy workloads (file creation, deletion, renaming). This option is often the default on modern systems.

Repairing

#

A file system in use should be boring and mostly invisible to the system administrator and user. However, crashes happen, and crash recovery needs to be considered. XFS provides xfs_repair to both check and repair a corrupted or damaged XFS filesystem.

It is typically run on an unmounted file system to ensure no conflicting operations occur while it replays the journal log to correct errors that might have occurred due to improper unmounting. The -n option allows us to check the file system for inconsistencies without actually making any changes.

systemctl stop nfs-server.service
umount /srv/nfs
xfs_repair /dev/sdc

We can find out the filesystem is damaged:

1. Upon boot, when mounting the filesystem, errors will be logged in the system journal. Use journalctl --boot to view it.
2. During execution, logged by the kernel. Use journalctl --dmesg to view it.

Resizing

#

XFS supports online resizing, while mounted and even while actively being used. However, if the disk is under heavy load, you might want to temporarily reduce I/O to avoid unpredictable behaviour.

XFS can grow online, but cannot shrink.

To extend the ZVOL holding the data disk, follow these steps:

1. Resize the disk image or block device.
2. Resize the filesystem inside the VM.

Use the terminal of the Proxmox host to resize the ZVOL:

zfs set volsize=+100G zfspool/vm-104-disk-0

After resizing, use lsblk to check that the OS has already detected the new size. When using using VirtIO/SCSI, the OS sees the size change immediately. Because we did not partition the disk before formatting it, we do not need to deal with partitions.

Finally, perform the second step in the VM terminal³:

xfs_growfs /srv/nfs

Make sure the disk is mounted before running xfs_growfs.

Defragmenting

#

A command worth note is xfs_fsr. FSR stands for file system reorganizer and it allows defragmentation of the extent lists of all files in a file system and can be run in background.

xfs_fsr /srv/nfs

By default it assigns 7200 seconds of time to perform such operations, in 10 passes, but that can be tweaked using the -t and -p options, respectively.

It may also be used on a single (large) file:

xfs_fsr /srv/nfs/myapp/pdf/file.pdf

Backing up

#

Although all normal backup applications can be used for XFS file systems, the xfsdump and xfsrestore commands from the xfsdump package are specifically designed for XFS backup.

xfsdump uses a special API to perform I/O based on file handles so that it does not generate inconsistent device snapshots on the raw block device. This command can perform backups to regular files on local and remote systems, and it supports incremental backups with a sophisticated inventory management system.

apt-get install --yes xfsdump

Let’s assume that we mounted a backup disk at /mnt/backups. We would start with a full backup (level 0):

xfsdump -l 0 -L "20250812-full-backup" -M "Full backup of NFS share" \
        -f /mnt/backups/nfs-full-backup-20250812.xfs /srv/nfs

In case of interruption, backup operations can be resumed using the -R option:

xfsdump -l 0 -L "20250812-full-backup" -M "Full backup of NFS share" \
        -f /mnt/backups/nfs-full-backup-20250812.xfs -R /srv/nfs

The next week, we would perform an incremental backup using -l 1, which specifies a level 1 backup, meaning it would include changes since the last level 0 backup.

xfsdump -l 1 -L "20250819-incr-backup" -M "Incremental backup of NFS share week 1" \
        -f /mnt/backups/nfs-incr-backup-20250819.xfs /srv/nfs

This backup would contain only files changed since the level 0 backup.

The following week, we would perform another incremental backup:

xfsdump -l 2 -L "20250826-incr-backup" -M "Incremental backup of NFS share week 2" \
        -f /mnt/backups/nfs-incr-backup-20250826.xfs /srv/nfs

This backup would only contain files changed since the level 1 backup.

Restoring

#

XFS offers a different command for restoring backups, named xfsrestore. We would start by listing the inventory of backups, which would provide us with a the available session IDs and session labels:

xfsrestore -I

Optionally, we would list the contents of a specific backup:

xfsrestore -I -f /mnt/backups/nfs-full-backup-20250812.xfs

When having to restore everything from scratch, we would follow these steps:

1. Stop the services using the NFS share.
2. Unmount the NFS share.
3. Format the disk again, if needed.
4. Restore the full backup.
5. Apply the incremental backups, in order.

systemctl stop nfs-server.service
umount /srv/nfs
mkfs.xfs -b size=8192 -s size=4096 /dev/sdc
xfsrestore -f /mnt/backups/nfs-full-backup-20250812.xfs /srv/nfs
xfsrestore -f /mnt/backups/nfs-incr-backup-20250819.xfs /srv/nfs
xfsrestore -f /mnt/backups/nfs-incr-backup-20250826.xfs /srv/nfs

If we wanted to restore a specific file at a given point in time, we would follow these steps:

1. Find which backup contains the file.
2. If found, restore just that file, using the session ID from the inventory.

xfsrestore -t -f /mnt/backups/nfs-incr-backup-20250826.xfs | grep proposal.odt
xfsrestore -S "2d129e2a-7c33-47a9-ac33-5a4862b594b1" -s myapp/docs/proposal.odt \
           -f /mnt/backups/nfs-incr-backup-20250826.xfs /srv/nfs/

An entire subdirectory could also be restored by specifying the directory path instead of a single file.

Summary of which backup file to use when:

We will be using Proxmox Backup Server to back up the entire VM and its disks (those marked for backup), including the NFS share. Still, xfsdump is a tool that can be used in specific cases to have a second, complementary backup copy of our data. For instance, the generated dumps could be sent to a different storage location for added redundancy.

Information

#

The xfs_info utility provides detailed information about the structure and characteristics of an XFS filesystem. It displays details like the file system size, block size, sector size, inode information, and other relevant parametres.

xfs_info /srv/nfs

The amount of information displayed can be quite extensive, so here is a table with an explanation of the various fields.

Meta-data section

Data section

Naming section

Log section

Realtime section

Metadata takes space

#

Let’s say that we format a 300G disk using XFS, as follows:

mkfs.xfs -b size=8192 /dev/sdc
mount -t xfs /dev/sdc /srv/nfs
df -h /srv/nfs

We would see something like 300G total, 4.3G used, 296G available, meaning that a our fresh filesystem already lost 4.3G (~1.4%, which is expected). This is because XFS is optimised for performance rather than minimal metadata footprint. Specifically:

• XFS pre-allocates metadata structures (like inode tables, allocation group headers, B+trees, journals), so the initial used space reflects this reservation.
• The larger the block size, the more space reserved. An 8 KB block size slightly increases the metadata footprint compared to 4 KB.
• The internal log (journal) takes space, ~150 MB in this case (19200 × 8 KB).
