Aligning block sizes of VM disks on Proxmox

In previous articles of this series we have seen how to set up an NFS server on a VM on Proxmox, and how to extend the disks used by that VM. For that, we used default values for the block sizes of the different layers involved in the I/O operations, which are:

• A ZFS storage pool made of two HDD in mirror mode, with ashift=12 (4096 bytes).
• A ZFS volume (ZVOL) for our data disk, with volblocksize=8K.
• An XFS filesystem on the data disk of the VM, with data.bsize=4096.

In this article we will focus on the block sizes of the different layers involved in the I/O operations of our NFS server.

Generally speaking, the easiest way to improve performance, minimise fragmentation, and make the most of our disk’s physical layout is:

1. To align the physical sector size of our disk with the block size of our ZFS storage pool.
2. To align the block sizes of the ZVOL and the filesystem inside the VM.

For that, we need to gather relevant statistics that allow us to make informed decisions.

ZFS ARC caching can affect the observed I/O patterns, especially for read workloads.

Current situation

#

If you followed the steps described in the NFS server on Proxmox VE article in this series, using Debian 12 Bookworm, at the moment you ought to have the following sector and block sizes:

Default values of ashift and volblocksize may differ depending on your hardware, the version of Proxmox you are using, and the version of ZFS it ships with. For instance, ZFS version 2.2 brings in a new default block size of 16K.

Most modern SSDs, particularly enterprise-grade ones, use 8KB logical sectors.

While the table above shows a disparity in the block size of our ZVOL, this is fine for most use cases. Furthermore, the specifics of each filesytem need to be considered in the equation. In the case of the ZVOL, setting volblocksize down to 4K most probably would not make it perform better because ZFS operates a lot of metadata, therefore the data-to-metadata ratio would be worse.

ZFS does not mix metadata and file data in the same volblocksize block, so metadata always incurs its own overhead, no matter how small the file is.

For example, with ashift=12 (i.e., 4K sector alignment) and the default redundant_metadata=all, ZFS writes two copies of metadata for redundancy. If the ZVOL has a volblocksize=8K, writing 8K of user data results in 1 × 8K data block and 2 × 4K metadata blocks (each redundant), for a total of 16K written.

However, if volblocksize=4K, writing the same 8K of user data as two separate 4K writes results in 2 × 4K data blocks and 4 × 4K metadata blocks (2 per data block, due to redundancy), for a total of 24K written.

ZFS storage pool

#

This terminology is used to describe the grouping of storage devices (HDD, SSD, etc.) into a single logical unit using the ZFS file system.

The ashift parametre controls the minimum block size ZFS will use for physical I/O on disk. Our HDD has a physical sector size of 4096 bytes, thus setting ashift=12 (4096 bytes) is fine.

However, using ashift=13 (8192 bytes) can still be a good idea when working with workloads with larger I/O (like our NFS server), which can benefit from the reduced metadata overhead and fewer IOPS required.

Regarding the value of ashift used when creating a ZFS pool, Proxmox offers a recommended value on the WebGUI which depends on the logical sector size of the disks. A general guideline would be:

• ashift=9 for older HDD disks with 512-byte sectors.
• ashift=12 for newer HDD disks with 4KB sectors.
• ashift=13 for SSD disks with 8KB sectors.

Once a ZFS vdev is created with a specific ashift value, it cannot be changed.

Write amplification

#

Write amplification in ZFS refers to the phenomenon where the file system ends up writing more data to the storage device than the amount of data originally intended to be written by the user or application.

This can happen because ZFS is a copy-on-write (COW) file system and uses a larger record size than the data being written, requiring it to rewrite larger blocks even when only a small portion of the data needs to be changed.

But how does write amplification happen? Suppose our NFS server performs plenty of 8K writes at a time and our ZFS pool has ashift=12 (4K). Then, ZFS tries to write 2 × 4K blocks (to match 8K) but, due to misalignment or COW, it might read-modify-write more 4K blocks than needed, leading to write amplification.

If ashift=13 (8K), then ZFS treats each 8K write as one atomic block. This leads to better alignment with our I/O patterns (writing 8K at a time), less overhead, less fragmentation, and less metadata churn.

Therefore, even though our HDD disk sectors are 4K, aligning ZFS to 8K avoids extra work when the application’s write size exceeds 4K.

In conclusion, if we observe, or predict, I/O patterns happening mostly in the range of 8K-16K, we are better off creating our ZFS storage pool with an ashift value of 13 instead of the default 12 offered by the WebGUI.

Measuring

#

Choosing a bigger block size when formatting a filesystem can offer a performance sweet spot for workloads that commonly read or write in chunks larger than the standard 4K.

However, as with any optimisation, the effectiveness of using 8K+ blocks ultimately depends on the typical request sizes and access patterns in your environment, and the specifics of the filesystem. So, how do we figure it out?

We are mostly interested in historical I/O stats, not real time. And because we have different layers involved, we need to measure at each level.

At the host level

#

Using the terminal at the host (the Proxmox node), we can observe logical and physical I/O stats of our ZFS storage pool, including metadata and ZFS overhead (checksumming, compression, etc.) of all ZVOLs and datasets underneath.

To see logical I/O stats, we can use the zpool iostat command from the zfsutils-linux package. The output table shows the average request size, including ZFS metadata overhead (not just raw application reads/writes), since boot.

zpool iostat -r zfspool

Although not essential in calculating the right volblocksize of our ZVOL, it is convenient to understand the suffixes and prefixes being used in the output table.

Regarding the ind and agg suffixes:

And regarding the sync and async prefixes.

Example output of a ZFS storage pool made of two HDD in mirror mode that was created using ashift=13 (for simplicity, and because trimming is not enabled, the last four columns have been cut out):

# zpool iostat -r zfspool
zfspool       sync_read    sync_write    async_read    async_write
req_size      ind    agg    ind    agg    ind    agg    ind    agg
----------  -----  -----  -----  -----  -----  -----  -----  -----
512             0      0      0      0      0      0      0      0
1K              0      0      0      0      0      0      0      0
2K              0      0      0      0      0      0      0      0
4K          1.87M      0  3.91M      0   217K      0  23.7M      0
8K          54.1M  15.7K  8.99M      0  11.6M  19.8K  17.5M  9.74M
16K         30.5K   396K  2.71M      0  5.06K   602K   948K  8.85M
32K          329K   539K   616K      5   193K   913K  1.64M  5.59M
64K         2.45K   633K   669K      6  1.67K  1.05M   281K  3.57M
128K          221   173K  4.35M  46.2K    621   957K  5.71K  3.82M
256K            0   157K      0  74.8K      0   613K      0  4.16M
512K            0   281K      0   105K      0   648K      0  2.09M
1M              0   280K      0  1.28M      0   671K      0  2.05K
2M              0      0      0      0      0      0      0      0
4M              0      0      0      0      0      0      0      0
8M              0      0      0      0      0      0      0      0
16M             0      0      0      0      0      0      0      0
------------------------------------------------------------------

These show counts of I/O operations categorised by I/O size and type (sync/async read/write, scrub and trim). The suffixes K and M represent kilo and mega, in base 1024.

In addition to zpool iostat, given that the ZVOL is exposed as a block device, we can also use iostat, from the sysstat package, to observe physical I/O statistics in real time:

iostat -xd /dev/zvol/zfspool/vm-104-disk-0

This tool shows kernel block-level I/O to the ZVOL device. Since our ZVOL is used by a VM, this shows how the host handles actual I/O coming from the guest. Relevant columns:

ZFS stores data in recordsize chunks for filesystems and volblocksize for ZVOLs. When guest I/O sizes mismatch volblocksize, ZFS must read-modify-write the full block, hurting performance.

If rareq-sz and wareq-sz are much smaller than the volblocksize of our ZVOL, meaning that the VM is issuing small reads/writes, this could increase IOPS load on the pool, result in write amplification and undermine compression and coalescing.

However, if rareq-sz and wareq-sz are much larger than the volblocksize of our ZVOL, meaning that the VM is issuing large read/writes, this would lead to efficient I/O ops, which is good. Larger I/O operations are more efficient and tend to align better with ZFS’s recordsize (defaults to 128K). Also, they allow ZFS to compress or dedup data more effectively and reduce write amplification on underlying disks.

# zfs get recordsize zfspool
NAME     PROPERTY    VALUE    SOURCE
zfspool  recordsize  128K     default

Additionally, high f_await can mean that the VM (our NFS server) is using fsync() often, and that our pool is not optimised for synchronous writes, e.g., no Separate LOG (SLOG) device, on a fast NVMe or SSD. This can point to synchronisation bottlenecks.

Example output of the same ZFS storage pool as before (for simplicity, only the four columns mentioned above are included):

# iostat -xd /dev/zvol/zfspool/vm-104-disk-0
Device           rareq-sz  wareq-sz    dareq-sz  f_await
zd16               126.40    277.94  1048576.00     0.00

ZFS stores metadata alongside data, and this overhead is more noticeable when block sizes are small or when fragmentation occurs.

At the guest level

#

Next, we need to get closer to the actual workload and its I/O patterns, so we need to measure from within the VM. For that, we can use iostat for real-time measuring, and sar for historical data, both in the sysstat package.

Let’s start by using iostat for real-time statistics with average request size:

iostat -xd /dev/sdc

Relevant columns:

For historical data, we need to enable sar. Start by editing the /etc/default/sysstat configuration file:

ENABLED="true"

And continue by enabling and starting the systemd timer:

systemctl enable sysstat
systemctl start sysstat

The daily files (saXX) will start populating (the number matches the day of the month):

ls -lh /var/log/sysstat/

The sysstat-collect.timer timer runs every 10 minutes, whereas the sysstat-summary.timer runs once a day. Let some time go by, then see the results using the sar command:

sar -d --dev=sdc

If you want to check a particular day, use the following command:

sar -d --dev=sdc -f /var/log/sysstat/saXX

You will notice that the default behaviour is to display a list of intervals and a last line with the average. Should you be intersted in a particular moment in time, you can filter the intervals:

sar -d --dev=sdc -s 00:00:00 -e 23:59:59

In the long run, we are mostly interested in the average.

Relevant columns:

Throughtput is useful for understanding workload volume, in context with request size.

If most requests are 8 KB or larger, it may make sense to align volblocksize and filesystem block size to 8K or more, which reduces write amplification and fragmentation. Conversely, too small blocks increase metadata and IOPS load.

Example output under heavy load:

# sar -d --dev=sdc -s 07:30:00 -e 08:50:00 -f /var/log/sysstat/sa24
07:30:13 AM  DEV     tps     rkB/s  wkB/s  dkB/s  areq-sz  await  %util
07:40:13 AM  sdc  424.57  52524.58   0.00   0.00   123.71   1.82  75.24
07:50:13 AM  sdc  509.13  85059.57   0.00   0.00   167.07   2.15  94.17
08:00:13 AM  sdc  758.21  76511.56   0.00   0.00   100.91   1.39  90.90
08:10:13 AM  sdc  508.45  63185.16   0.00   0.00   124.27   1.61  80.03
08:20:13 AM  sdc  290.09  63357.08   0.00   0.00   218.40   1.69  43.41
08:30:07 AM  sdc  622.21  61181.33   0.00   0.00    98.33   0.85  47.76
08:40:13 AM  sdc  161.86  31132.86   0.00   0.00   192.35   1.81  25.46
Average:     sdc  467.13  61807.10   0.00   0.00   132.31   1.54  65.25

Mapping metrics

#

A number of metrics can be taken into consideration when tuning block sizes, but these are the most relevant ones:

Let’s try to map these metrics to the output provided by sar and zpool iostat.

Average request size

#

Average request size is the mean amount of data read or written per I/O operation, typically calculated as total bytes transferred divided by IOPS.

Rule of thumb: To estimate a good ZVOL volblocksize, find a typical average request size from these and align it, e.g., if it is consistently ~16K, set volblocksize accordingly.

IOPS vs bandwidth

#

Input/Output Operations Per Second (IOPS) measures how many read/write actions happen per second, while bandwidth refers to the total amount of data transferred per second (MB/s).

We will use these to infer the type of workload:

CPU usage per byte transferred

#

CPU usage per byte transferred is the amount of CPU time or percentage consumed for each byte of data moved to or from disk, reflecting efficiency of I/O handling.

We cannot measure CPU per byte directly in sar, but we can infer:

On the one hand, sar -u provides information about CPU utilisation.

%user + %system reflects the NFS server demand, while %iowait reflects disk latency.

Let’s calculate %CPU used:

Let’s say we have the following data from our sar -u command:

# sar -u --dev=sdd -s 07:30:00 -e 08:50:00 -f /var/log/sysstat/sa24
07:30:13 AM  CPU  %user  %nice  %system  %iowait  %steal  %idle
07:40:13 AM  all   1.07   0.00     1.05    18.59    0.00  79.28
07:50:13 AM  all   1.25   0.00     0.88    22.95    0.00  74.92
08:00:13 AM  all   1.17   0.00     0.96    22.13    0.00  75.74
08:10:13 AM  all   2.13   0.00     1.34    19.26    0.01  77.26
08:20:13 AM  all   4.44   0.00     2.72     7.91    0.01  84.92
08:30:07 AM  all   4.22   0.00     2.65     9.44    0.01  83.68
08:40:13 AM  all   2.17   0.00     1.34     4.77    0.01  91.71
Average:     all   2.34   0.00     1.56    15.02    0.01  81.07

Then, we would have:

If you are more interested in application CPU usage, you can sum %user and %system:

This excludes I/O wait time, which represents time the CPU is idle waiting for I/O. So, high %iowait is not usage by the NFS server, but rather a sign of storage bottleneck.

On the other hand, our previous use of sar -d provided us with the necessary disk I/O statistics to calculate MB transferred:

Then, we would have:

So, the CPU usage per MB would be:

This means the device used 31% of one CPU core to transfer 1 MB per second on average. In other words, for each 1 MB/s of throughput, the device consumes 31% of a CPU core. If we do the same calculations using the application CPU usage mentioned above, we get that the device consumes 7% of a CPU core for each 1 MB/s of throughput.

This difference means that the NFS server is not taking more CPU because it is blocked on slow disk I/O, not because the stack is inefficient.

Rule of thumb: Try using a bigger volblocksize in the ZVOL and a bigger ashift in the ZFS storage pool and see if that reduces the amount of CPU usage per MB/s.

Interpretation

#

On the one hand, the areq-sz colum on sar tells us that our guest is issuing I/O requests that average 132.31 kB on a ZVOL with block size of 8K. This means each guest I/O is split across multiple 8K ZVOL blocks.

On the other, the block distribution displayed by zpool iostat tells us that most of the I/O requests happen at 8K and 16K, which includes our ZVOL and others in the same node, and a fairly big number happen between 128K and 1M, probably because of ZFS ARC and transaction group aggregation.

Metadata overhead scales with the number of blocks, not their size.

Therefore, should we increase the volblocksize of our ZVOL to 16K to get fewer IOPS, reduce metadata overhead and write amplification, and better align it with actual guest workload sizes? It seems likely beneficial given these I/O patterns but, as always, it is about trade-offs.

Rule of thumb:

• If average request size > 2× volblocksize, increase volblocksize.
• If 80%+ of writes are > volblocksize, also increase it.
• Match volblocksize to XFS block size.
• Prefer 8K+ blocks for large sequential workloads, NFS/VM image storage and reduced metadata overhead.
• Keep volblocksize ≤ 16K unless workload has clear benefit (snapshots cost more at higher values).

Database workloads often benefit from smaller block sizes (4K-8K) for better random I/O performance, while large sequential workloads (like media files) benefit from larger blocks (16K-128K).

I/O size mismatch

#

When the typical I/O size from the guest (areq-sz) does not align well with the ZVOL’s volblocksize, two key problems arise: internal fragmentation and write amplification.

Internal framentation is wasted space inside blocks. For example, if your volblocksize is 64K but most writes (areq-sz) are 8K, each write may waste up to 56K, depending on the filesystem layout and how blocks are reused. Therefore, we want to match request size to block size as much as possible to avoid unused padding.

The guest OS never sees this waste, but ZFS tracks and allocates the full block size, so pool space fills up faster than expected.

Write amplification happens when one guest write results in multiple writes at the underlying storage layer. This occurs when:

• Guest writes are smaller than volblocksize.
• Copy-on-write forces read-modify-write cycles.
• Metadata, padding, and block pointer overhead add extra writes.

Traditional write amplification refers to how many bytes are written to disk per logical byte written by the application. We will not be calculating exactly that, but rather a simplified version based on allocated size and logical used space, which we will call storage amplification.

In ZFS, even with compression, small writes incur overhead due to block size alignment and COW. When using synchronous writes, amplification can get worse unless a fast SLOG is available.

Matching areq-sz and volblocksize, and using appropriate compression and sync settings, helps reduce both fragmentation and amplification.

Workload block size

#

To determine the workload block size, we can use the zpool iostat command to see how ZFS handles writes.

We can extract the following details:

• writes shows how many write operations the workload made.
• nwritten is what ZFS actually pushes to disk.
• nwritten/writes gives the average write size per operation (the workload block size).

Rule of thumb: What indicates the need for a larger block size? You compare nwritten/writes (the workload block size) to your volblocksize and:

• If your workload is writing 128K per operations, but your volblocksize is 4K, ZFS will break it into many chunks, leading to overhead, more metadata, and more IOPS.
• If ZFS writes (nwritten) are significantly smaller or larger than the workload size, there is a mismatch, leading to write amplification or underutilization, respectively.

Allocated size

#

Allocated size (asize) represents the actual number of on-disk bytes that a block occupies after compression, padding and metadata, aligned to the ashift (minimum sector size).

So, asize represents the true cost on the physical disks and will always greater than or equal to the compressed size. It is called allocated size because ZFS allocates in units of ashift (e.g., 8K if ashift=13), even if the actual data is smaller.

This will allow us to calculate the amplification, which is the number we care about when deciding if our current block size is too small.

We will gather part of the necessary data to calculate asize via the zfs get command:

zfs get used,logicalused,compressratio zfspool/vm-104-disk-0

Example output:

# zfs get used,logicalused,compressratio zfspool/vm-104-disk-0
NAME                   PROPERTY       VALUE  SOURCE
zfspool/vm-104-disk-0  used           670G   -
zfspool/vm-104-disk-0  logicalused    499G   -
zfspool/vm-104-disk-0  compressratio  1.01x  -

A compressratio of 2.0x would mean that for every 2 bytes of logical data, ZFS would be using only 1 byte of physical storage.

Estimating

#

ZFS does not show actual allocated size per ZVOL directly, but we can try to estimate it using zdb:

zdb -dddd zfspool/vm-104-disk-0

The output of that command shows us three objects:

We want to focus on object 1, which is our virtual disk content. Example output of object 1:

Object  lvl   iblk   dblk  dsize  dnsize  lsize   %full  type
     1    4   128K     8K   495G     512   600G   82.78  zvol object

Relevant columns:

Example output of our ZVOL object with volblocksize of 8K:

# zdb -dddd zfspool/vm-104-disk-0 | awk '/zvol object/ {print "dsize=" $5, "lsize=" $7}'
dsize=495G lsize=600G

We can now calculate the storage amplification (or allocation efficiency):

$ \text{Storage amplification} = \frac{\text{dsize}}{\text{lsize}} = \frac{495}{600} \approx 0.825 $$

This shows ZFS stores only 82.5% of the logical size on disk, thanks to compression and efficient block use. A few notes worth mentioning in regards to the storage amplification threshold:

• Values below 0.7 indicate very good compression, but may also suggest that the workload is not writing enough data to fill the blocks efficiently.
• Values of 0.7-0.9 indicate good compression and efficient block use.
• Values of 1.1-1.5 suggest block size mismatch.
• Values above indicate serious inefficiency.

In our example, the slight space savings align with the low compression ratio shown by zfs get compressratio, which reported 1.01x.

It is normal that the space reported by df inside the VM is larger than logicalused, because df includes filesystem metadata, while logicalused counts raw writes to the block device.

Rule of thumb: If storage amplification is greater than 1.0, ZFS is using more space than it receives from the guest. This usually means:

• The volblocksize is too small for the workload’s typical request size.
• ZFS is doing read-modify-write due to misaligned or sync-heavy writes.
• Metadata or COW overhead is significant.

In such cases, consider increasing the ZVOL’s volblocksize, ensuring alignment with the guest filesystem, and evaluating whether compression is needed for the workload.
